OMNIWISE AI BOX
Gold-ONX16-Fanless
OMNIWISE AI BOX
Gold-ONX16-Fanless
The OmniWise AI Box, Model 01-ONX16- 31, stands out as a dependable and robust AI inference solution. This fanless edge AI system offers flexible expansion capabilities, including support for 2x USB 3.0 ports and 1x USB OTG (Micro), allowing for the connection of up to 2x USB cameras. It’s equipped with a variety of I/O and expansion possibilities, catering to diverse AI deployment requirements. At its core, the device is powered by an NVIDIA® Jetson Orin™ NX, achieving up to 100 TOPS of AI computing performance, and it’s compatible with the NVIDIA® Jetson Orin Nano™ module as well. Both configurations provide the necessary bandwidth and power to enhance and scale video inputs for edge AI inference tasks efficiently.
• Support NVIDIA Jetson Orin™ NX and Orin Nano™ module
• 2x USB 3.0 Ports (Type-A)
• 1x USB OTG (Micro)
• 1x 10/100/1000 Base-T RJ45
• 1x HDMI 2.0
• 1x 3.3V UART, 1x I2C bus, 2x SPI bus, 4x GPIO
• Wide input voltage range from 9 to 36V DC
• Operating Temperature -25°C ~ +85°C
• Fanless Design
Overview
Utilizing the NVIDIA Jetson Orin NX Module, the OmniWise AI Box offers an optimal solution for managing embedded IoT applications. Tailored for tasks like video analytics, robotics, and natural language processing, the OmniWise AI Box is adept at handling diverse applications. With a capacity to drive up to 100 TOPS, it delivers unparalleled AI performance and power efficiency, enhancing the capabilities of your projects significantly.
| Jetson Module | Jetson Orin Nano – Orin NX |
|---|---|
| AI Performance | 100 TOPS (INT8) |
| GPU | 1024-core NVIDIA Ampere architecture GPU with 32 tensor cores |
| CPU | 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
| Memory | 4GB 64-bit LPDDR5 8GB / 16GB 128-bit LPDDR5 |
| Dimensions | 124mm(L) x 86mm(W) x 74mm(H) |
| MISC / IO Connector | 1x 3.3V UART, 1x I2C bus 2x SPI bus, 4x GPIO |
| DL Accelerator | 2x NVDLA v2.0 |
| Power Configuration | 10W – 25W |
| Display Output | 1x HDMI 2.0 |
| Camera Inputs | 2x MIPI CSI-2 15 Pin |
| Networking | 1x 10/100/1000 Base-T RJ45 |
| Wireless | 1x M.2 E-Key – 2230 |
| Storage | 1x NVME M.2 M-Key SSD – 2280 |
| Input Power | 9V-36V DC Input |
| Operating Temperature | -25°C to +85°C |
| Weight | 909g (Including Antenna) |
| Video Encode | 1x 4K60 | 3x 4K30 | 6x 1080p60 12x 1080p30 (H.265) H.264, AV1 |
| Video Decode | 1x 8K30 | 2x 4K60 | 4x 4K30 9x 1080p60 | 18x 1080p30 (H.265) H.264, VP9, AV1 |
| Number | Name | Description |
|---|---|---|
| 1 | Heatsink | Passive Heatsink |
| 2 | Case | 124mm(L) × 86mm(W) × 74mm(H) |
| 3 | Micro USB Port | USB OTG(Micro) |
| 4 | HDMI Port | HDMI (3840× 2160 at 60Hz ) |
| 5 | USB Port | 2× USB 3.0 Ports (Type A) |
| 6 | Ethernet Port | 1× 10/ 100/ 1000 Base-T RJ45 |
| 7 | DC Port | Voltage Range 9V – 36V |
| 8 | Operating Temperature | -25°C ~ +85°C |
| 9 | CSI Port | 2 Lane MIPI CS-2, 15 pin FPC 1mm Pitch Connector |
| 10 | Antenna Port | Antenna Port |
| 11 | Force Recovery Button | Button for Recovery Mode |
| 12 | Reset Button | System Reset Button |
| 13 | Debug Connector | 1× UART for Debug |
| 14 | Multi I/O Connector | 1× 3.3V UART, 1× I2C bus, 2× SPI bus, 4× GPIO |
