The Gauntlet AI Kit powered by NVIDIA Jetson T5000 is a production-ready, high-performance platform developed for Physical AI, robotics, and edge AI applications, featuring ultra-fast networking, advanced camera integration, and industrial I/O infrastructure.
Gauntlet NVIDIA Jetson Thor 5000 AI Kit
Out of stock
SKU: AGX301-JT5000-KIT
Category: Ready-to-Use AI Kits
Tags: AGX Thor, Jetson AGX Thor AI Kits, T5000
Description
The Connect Tech Gauntlet AI Kit, supplied with the NVIDIA Jetson T5000 module, is an advanced embedded AI platform designed for Physical AI, robotics, autonomous systems, and high-performance edge AI applications. It combines industrial-grade durability, high-speed data communication, and advanced sensor integration in a single system to bring real-time AI workloads into field deployments.
Designed to unlock the compute performance of the NVIDIA Blackwell architecture-based Jetson T5000 module, Gauntlet supports next-generation Physical AI applications with multi-camera support, high-bandwidth networking, and expandable storage options. It provides an ideal platform for robotics systems, smart city solutions, industrial automation, autonomous vehicles, and image analytics projects.
Key Features
* High-performance AI compute capacity with the NVIDIA Jetson T5000 module
* Advanced camera integration with 16-Lane MIPI CSI-2 support
* Support for GMSL3, GMSL2, FPD-Link III, SDI, and HDMI camera ecosystems
* High-speed data transfer with 2x 10GbE + 2x 1GbE Ethernet
* Dual M.2 NVMe storage support
* LTE / 5G and Wi-Fi expansion options
* USB 3.2, CAN 2.0b, UART, I2C, SPI, GPIO, and PWM interfaces
* Compact, production-ready design optimized for industrial use
Gauntlet AI Kit provides a high-performance, production-ready foundation for teams developing end-to-end scalable AI solutions from prototypes to field deployments. It is optimized for multi-sensor processing, real-time decision-making, and Generative AI-based edge applications.
Brand
Connect Tech
Specifications
| Compatibility | NVIDIA® Jetson T5000 |
| Networking | 2x 10GBASE-T (10G Ethernet) 2x 1000BASE-T (1G Ethernet) |
| Display | 1x DisplayPort |
| Camera Inputs | 1x 16-Lane MIPI Expansion Connector Direct interface with MIPI CSI, GMSL2, or FPD-Link III image sensors |
| USB | 1x USB 3.2 Port (Type-C – OTG Compatible) 1x USB 3.2 Port (Type-C) |
| Storage | 2x M.2 Key M 2280 NVMe |
| UART | 2x UART1 and UART2 @ 3.3V levels 2x RS-232/485 UART |
| I2C / SPI | 2x I2C Channels @ 3.3V IO 2x SPI Channels @ 3.3V IO |
| CAN Connectivity | 4x Isolated CAN 2.0b Ports |
| GPIO | 4x 3.3V GPI Inputs 6x 3.3V GPO Outputs (2x with PWM Support) 1x 3.3V Power Pin (1A) |
| Expansion Slots | 1x M.2 Key E 2230 Wi-Fi/BT (PCIe/USB2) 1x M.2 Key B 3042/3052 (LTE/5G – USB3) with Micro SIM |
| Input Power | +36V to +60V DC Wide Input Power (6-Pin Mini-Fit Jr. Connector) |
| Buttons | Power, Reset, Recovery (Tactile buttons and fine-pitch pin header connector) |
| Dimensions | 155 mm x 126 mm |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
